ANDRITZ Pumps

High-pressure pumps

ANDRITZ multi-stage high-pressure pumps meet the highest customer requirements in terms of efficiency, service life, serviceability and economy.

ANDRITZ high-pressure pumps are designed for highest flexibility. Numerous horizontal and vertical models allow for efficient building designs. A variety of material and sealing versions guarantee optimal adaptability to the medium. Different hydraulic systems for each pump size enable a selection at the best efficiency point. These pumps are used for various high-pressure municipal and industrial applications, e.g. water supply, irrigation, circulation, boiler feed, and drainage.

High-pressure pumps, MP series

The high standard of the ANDRITZ multi-stage high-pressure pumps, MP series, is based on decades of experience in designing hydraulic machines and on extensive process know-how. The pumps are installed for conveying clean and slightly contaminated media such as cold and hot water, condensate, deionized water, oils, and suspensions.

The multi-stage pumps in the MP series are designed according to a strict modular system. With this system, different design variants can be supplied according to the customer‘s requirements quickly, easily and economically, without customizing and using a minimum number of components. For more information on our high-pressure pumps from the MP series please have a look at our brochures in the sidebar or contact us directly.

ANDRITZ high-pressure pumps, MP series

© ANDRITZ

ANDRITZ - MP series

Design:multi-stage, closed impellers
Head:up to 800 m
Flow rate:up to 400 m³/h
Pressure:up to 100 bar
Temperature:up to 140° C

Product benefits

  • Horizontal design with a closed impeller and external bearing assemblies on both sides
  • Axial heat expansion by the pump rotor is absorbed internally without influencing the coupling alignment
  • Easy maintenance

High-pressure pumps, HP series

ANDRITZ multi-stage high-pressure pumps, HP series, are used for various industrial applications such as water supply, irrigation, for hot and cold water circulation, fire fighting, boiler feed and pressure boosting installations. They are suitable for transporting all clean or slightly dirty non-corrosive liquids up to a viscosity of 150 mm²/s ( cSt). Under difficult suction conditions (low NPSH-available), the pump can be provided with an axial inlet for cavitation-reducing flow entry pattern into the first stage impeller. For more information on our high-pressure pumps from the HP series please have a look at our brochures in the sidebar or contact us directly.

ANDRITZ high-pressure pumps, HP43 series

ANDRITZ high-pressure pumps, HP43 series

© ANDRITZ

ANDRITZ - HP series

Design:multi-stage, high-pressure
Head:up to 400 m
Flow rate:up to 800 m³/h
Pressure:up to 40 bar
Temperature:up to 140° C
Speed:up to 3,600 rpm

Product benefits

  • Numerous hydraulic units per model size guarantee a design at the optimal operating point
  • High efficiencies owing to optimized hydraulics
  • Optimal adaptability to the medium to be pumped
  • All wearing parts are renewable without additional work on the casing parts

High-pressure pump, HPM (High-Pressure Mining) series

ANDRITZ multi-stage high-pressure pumps, HPM series, are used for water management and emergency drainage in surface and underground mining. The pump is installed for removing mine water from operating areas and water level management. ANDRITZ high-pressure pumps in the HPM series have been specially developed for a wide variety of operating conditions in mining. Due to numerous special features, the product is designed to meet a wide range of requirements. For more information on our high-pressure pumps from the HPM series please have a look at our brochures in the sidebar or contact us directly.

ANDRITZ High-pressure pump, HPM series

ANDRITZ High-pressure pump, HPM series

© ANDRITZ

ANDRITZ - HPM series

Design:multi-stage, high-pressure
Head:up to 1,200 m
Flow rate:up to 1,300 m³/h
Pressure:up to 140 bar
Temperature:up to 105° C
Speed:up to 1,800 rpm

Product benefits

  • Maximum operational reliability
  • Long service life
  • High cost-effectiveness
