Depending upon the location, fuel availability and quality can vary greatly according to the season. With emissions limits becoming more strict, there is a need for power generation technology that is able to utilize alternative low-quality fuels with high efficiency and availability – and with minimal emissions.
EcoFluid BFB solutions
BFB is the best technology for the combustion of a wide range of biomass and alternative fuels for steam and power generation. The high heat capacity of the fluidized bed evens out the fluctuations caused by fuel quality variations to effectively maintain stable combustion.
EcoFluid boilers are designed in standardized modules which can be flexibly configured to achieve the results of a custom-tailored system at a lower capital cost. EcoFluid boilers are typically natural circulation high-pressure steam boilers, equipped with auxiliaries and emission reduction technologies as required.
EcoFluid BC for biomass
The EcoFluid Biomass Concept (BC) is designed for different biomass fuels. The total system encompasses equipment for fuel feeding into the boiler, water-cooled fluidizing grid design, and efficient bottom ash and fly ash handling systems. The boiler is typically highly instrumented and automated for easy operation.
EcoFluid AC for alternative fuels
The EcoFluid Advanced Concept (AC) is specially designed for combusting challenging fuels such as paper sludge, agricultural residues, and waste wood. The boiler has an open nozzle grid for reliable discharge of inert coarse particles and meets all relevant requirements of the Waste Incineration Directive.
EcoFluid RC for waste
The EcoFluid Residue Concept (RC) is an excellent choice for Refuse-Derived Fuel (RDF) fractions and other waste materials with challenging fuel properties. These fuels can even be used in combination with sewage sludge. The open nozzle grid is specially designed for waste fuels and the boiler features a solid radiation and horizontal back pass design.
